NFC RFID antenna sticker jewelry security tags labels

RFID Jewelry Tags are used in the jewelry industry for inventory management and asset tracking.HF Jewelry Tag, working at 13.56MHz, is mainly used for the identification of jewelry. Each jewelry tag has a globally unique ID number and records the weight, purity, grade, location, warehouse, shelves, and other information of the jewelry, which is convenient for the management of jewelry.HF Jewelry Tag is widely used in the identification and tracking of jewelry pieces like rings, necklaces, earrings, and sunglasses, watches, and other accessories.

Chip	Ucode 8
Dimensions	66. 5*11mm
Thickness	0. 07mm
Material	AL+PET
Application Temp	-20~70℃
Operating Temp	-20~70℃
Memory	TID 96bits; EPC 128bits
Frequency range with he best performance	900-960MΗz
Printing	thermal transfer printing Logo,barcode printing,QR code printing.
Chip customize	Alien H3,Monza R6,U code 7,U code 8,color-color
Color ancolor-coloris	Basis on customer’s artwork ready
Ready date	1000pcs—5 day, 5000 pcs—7 days,20000 pcs—10 days



860-960MHz Chips（portion）
Chip Name	Protocol	Capacity	Frequency
Alien H3（Higgs 3）	ISO18000-6C	512 bits	860~960 MHz
Alien H490 (Higgs 4)	ISO18000-6C	513 bits	860~960 MHz
Impinj Monza 4	ISO18000-6C	96 bits	860~960 MHz
Ucode 7	ISO18000-6C	128bits	860~960 MHz
Ucode 8	ISO18000-6C	EPC 128bits	860~960 MHz
UCODE G2iL	ISO18000-6C	128 bits	860~960 MHz
M4QT	ISO18000-6C	512bits	860~960 MHz
Monza R6	ISO18000-6C	96bits	860~960 MHz
Monza R6-P	ISO18000-6C	32bits	860~960 MHz
EM4124	ISO18000-6C	96bits	860~960 MHz
EM4126	ISO18000-6C	208bit	860~960 MHz
EM4325	ISO18000-6C	’-	860~960 MHz
ME4423	ISO18000-6C	64bits	860~960 MHz
