RFID UHF clothing tag ARC RFID apparel label smart garment tag qr code round hole custom
RFID Apparel Tags are used for smart retail management, apparel tracking management, cloth warehouse management, asset tracking, logistics, etc.Application Instructions:RFID hang tag is in the middle of the paper layer embedded in a smart “core”, and can
| Product name | ARC rfid retail tag |
| Chip type | Ucode9 |
| Material | PVC |
| Frequency | 860-960mhz |
| Application | Inventory Management /Clothing Management |
Share to:
RFID Apparel Tags are used for smart retail management, apparel tracking management, cloth warehouse management, asset tracking, logistics, etc.
Application Instructions:
RFID hang tag is in the middle of the paper layer embedded in a smart “core”, and can be directly on the surface of printing, anti-counterfeiting ability, reliable inspection, and background statistical characteristics accurately, and because of them the only global code is embedded with the chips, the clothing tags can read and write using a handheld device, high efficiency, the literacy rate for 0.3 seconds/every time, and completely solve the multi-purpose phenomena.


| Chip | M4E or M4QT |
| Dimensions | 68*20mm |
| Thickness | 0.07mm |
| Material | AL + PET |
| IP Rating | N/A |
| Application Temp | -20~70℃ |
| Operating Temp | -20~70℃ |
| Memory | TID 96bits; EPC 496bits; USER 128bits |
| Frequency range with the best performance | 902-928MHz |
| IC Life | Write endurance of 100,000 cycles Date retention of 10 years |
| Protocol | ISO/IEC 18000-6C |
Feature:
*With UHF technology, hundreds of tags can be read at a time
*Reading distance: >9m
*100% non-magnetic material, can be used in the field of clothing management
*Support high-speed read-write
Application:
*Product Identification
*Inventory Management
*Asset Management
*Carton Management
*Clothing Management
| 860-960MHz Chips(portion) | |||
| Chip Name | Protocol | Capacity | Frequency |
| Alien H3(Higgs 3) | ISO18000-6C | EPC 96-496bits、User 512bits | 860~960 MHz |
| Alien Higgs 4 | ISO18000-6C | EPC 128bits、User 128bits | 860~960 MHz |
| Impinj Monza 4 | ISO18000-6C | 96 bits | 860~960 MHz |
| Ucode 7 | ISO18000-6C | 128bits | 860~960 MHz |
| Ucode 8 | ISO18000-6C | EPC 128bits | 860~960 MHz |
| Ucode 8m | ISO18000-6C | EPC 96bits、User 32Bit | 860~960 MHz |
| Ucode 9 | ISO18000-6C | EPC 96bits、User 32Bits | 860~960 MHz |
| UCODE G2iL | ISO18000-6C | 128 bits | 860~960 MHz |
| U Code DNA | ISO18000-6C | EPC 128bits、User 3072Bits | 860~960 MHz |
| U Code HSL | ISO18000-6C | UID 8Bytes 、User 216Bytes | 860~960 MHz |
| Monza 4D | ISO18000-6C | EPC 128bits、User 32bits | 860~960 MHz |
| Monza 4QT | ISO18000-6C | 512bits | 860~960 MHz |
| Monza R6 | ISO18000-6C | 96bits | 860~960 MHz |
| Monza R6-P | ISO18000-6C | 32bits | 860~960 MHz |
| EM4124 | ISO18000-6C | 96bits | 860~960 MHz |
| EM4126 | ISO18000-6C | 208bit | 860~960 MHz |
| ME4423 | ISO18000-6C | User 160/64bits | 860~960 MHz |
